Heatmap of effects between variables, such as correlations

Draws a heatmap of e.g. correlations between variables (see perform_correlation_tests). It is possible to draw only the lower triangular of the heatmap, order rows and columns with hierarchical clustering, and add circles for p-values.

Usage

plot_effect_heatmap(
  data,
  x,
  y,
  effect,
  p = NULL,
  p_limit = 0.1,
  point_size_range = c(1, 6),
  log2_effect = FALSE,
  discretize_effect = FALSE,
  breaks = 5,
  clustering = TRUE,
  dist_method = "euclidean",
  clust_method = "ward.D2",
  lower_tri = FALSE,
  reverse_y = TRUE,
  use_coord_fixed = TRUE,
  symmetric_aspect_ratio = TRUE,
  title = NULL,
  subtitle = NULL,
  fill_scale = NA
)

Arguments

data

a data frame with x and y variables and the effect

x, y

the column names of data with the x and y variables

effect

the column name of the effect, e.g. correlation

p

optional, the column name with p-values. If provided, points that scale by p-value are drawn on top of the heatmap tiles

p_limit

numeric, only p-values below the limit are plotted as points

point_size_range

a numeric vector of length 2. The upper and lower limits for the point sizes. This needs to be adjusted to make the point size look good when compared to the tiles

log2_effect

logical, whether the effect should be plotted on a logarithmic scale (in case of fold change etc.)

discretize_effect

logical, whether the effect range should be divided into discrete levels instead of using a continuous scale. Can sometimes make patterns more visible, but the hard limits can blur the big picture as well.

breaks

if discretize_effect = TRUE, either the number of breaks or the points where to cut for the levels, see cut

clustering

logical, whether the order of rows and columns should be ordered by hierarchical clustering?

dist_method

distance method used in clustering, see dist

clust_method

clustering method used in clustering, see hclust

lower_tri

logical, should only the lower triangular be plotted?

reverse_y

logical, if clustering = FALSE, lower_tri = FALSE, should the order of the y-axis be reversed so that the diagonal is from top left to bottom right?

use_coord_fixed

logical, should the heatmap tiles be squares? If yes, this uses coord_fixed

symmetric_aspect_ratio

logical, should the plot panel be a square? If yes, uses ggplot2::theme(aspect.ratio = 1).

title, subtitle

the title and subtitle of the plot

fill_scale

fill scale for the heatmap as returned by a ggplot function. Set to NA to choose the appropriate scale based on the class of the effect variable.

Value

A ggplot object.

Details

All missing effects between variables are replaced by 0 before clustering, since hclust can't deal with missing values.

See also

cut for discretizing the effect, dist for distance calculation for clustering, hclust for hierarchical clustering.

Examples

data(example_set)
# Compute correlations between variables
correlations <- perform_correlation_tests(example_set,
  x = rownames(example_set),
  duplicates = TRUE
)
#> INFO [2025-06-23 22:37:41] Starting correlation tests.
#> INFO [2025-06-23 22:37:41] Performing correlation tests for single object
#> INFO [2025-06-23 22:37:43] Correlation tests performed.

# Minimal example
plot_effect_heatmap(correlations,
x = "X", y = "Y", effect = "Correlation_coefficient")


# Lower triangular with discrete effect and p-value dots
